Port
Screwed Available BSP / NPT, Flanged Available 150 Class
Size
1/2″ TO 2″
End Connection
Screwed / Flange
Body Material
SS ASTM A351 Grade CF8 / CF8M
Diaphragm
Nitrile (NBR)
-30°C to 90°C
Media Temp
-10°C to 70°C
Circumstance Temp
Air, Water, Gas, Mild Vacuum, Light Oil
Pressure
(1/2″, 3/4″ AND 1″ 0 to 7 BAR)
(1-1/2″ and 2″ 0 to 5 BAR)
(1-1/2″ and 2″ 0 to 5 BAR)
Main Features
Internal parts are in superior corrosion resistance steel. Suitable for food, pharma and chemical applications.
Operating Voltage
| 24AC | 110AC | 230AC | 12DC | 24DC |
| 5W | 8W | 8W/9W | 10W/12W | 11W/17W |
Coil Features
High reliability, unaffected by voltage surges. Easy coil replacement.
Coil Housing
Metallic round enclosure coil, moulded square coil
Other Specification
Available on Request (0 BAR to 2 BAR).
