Port :
1″, 1-1/2″ (Available in BSP / NPT)
End Connection :
Screwed
Body Material :
Aluminum Pressure Die Cast
Diaphragm :
| Nitrile (NBR) |
|---|
| -30°C to 90°C |
Media Temp :
-10°C to 70°C
Circumstance Temp :
-10°C to 70°C
Media :
Air
Main Features :
Internal Parts are in superior corrosion resistance steel,
Suitable for Air Pollution Control
System, Bag Filter Machine
Suitable for Air Pollution Control
System, Bag Filter Machine
Operating Voltage :
| 24AC | 110AC | 230AC | 12DC | 24DC |
|---|---|---|---|---|
| 5W | 8W | 8W / 9W | 10W / 12W | 11W / 17W |
Power Consumption :
Refer Above Voltage Table
Coil Features :
High Reliability. Unaffected by Voltage Surges.
Easy coil changes. Coil lockable in 4×90° position or freely movable in between as require.
Easy coil changes. Coil lockable in 4×90° position or freely movable in between as require.
Coil Housing :
Epoxy square coil, Metallic round enclosure
Working Pressure :
0.5 to 9 BAR
Note :
Use of filter in the inlet port is recommended.
