Port :
Screwed Available BSP / NPT
Size :
1/8″, 1/4″, 3/8″, 1/2″
End Connection :
Screwed
Body Material :
SS ASTM A351 Grade CF8 / CF8M, Forged Brass, Aluminium
Diaphragm :
| Nitrile (NBR) | EPDM | Viton (FKM) |
|---|---|---|
| -30°C to 90°C | -10°C to 140°C | -10°C to 180°C |
Media Temp :
-10°C to 70°C
Circumstance Temp :
-10°C to 70°C
Media :
Air, Water, Chemical, Gas, Oil, Diesel, Kerosene, LPG.
Operating Voltage :
| 24AC | 110AC | 230AC | 12DC | 24DC |
|---|---|---|---|---|
| 5W | 8W | 8W | 10W / 12W | 11W / 17W |
Power Consumption :
Refer Above Voltage Table
Coil Features :
High Reliability. Unaffected by Voltage Surges. Easy coil changes. Coil lockable in 4×90° positions or freely movable in between as required.
Coil Housing :
Epoxy square coil, Metallic round enclosure, Flameproof enclosure, Weatherproof enclosure.
Other Specification Data :
Available on Request (1 BAR to 20 BAR)
Note :
Use of filter in the inlet port is recommended.
